Mersen A2D5-6/10R - Class L Fuse 5A 250V (200kA AIC)

Mersen A2D5-6/10R is a Class L low-voltage fuse designed for high-interrupting capacity circuit protection in industrial electrical systems. This 250V AC/DC rated fuse features a 5A current rating with a 200kA interrupting capacity at rated voltage, housed in a compact 2" diameter single-barrel construction with robust terminal connections. It meets stringent safety standards including CSA C22.2 No. 248.12 and UL 248-12 (File E2137) certifications, ensuring reliable performance in demanding environments. The fuse is commonly deployed in motor control centers, switchgear, and industrial power distribution systems requiring high-fault current protection.

Key Features & Specifications

• Type: Class L time-delay fuse with ferrule terminals
• Voltage Rating: 250V AC/DC
• Current Rating: 5A
• Dimensions: 2" diameter
• Standards: CSA C22.2 No. 248.12, UL 248-12 (File E2137)
• Applications: Industrial power distribution, motor protection
• AIC rating: 200kA@250V
• Barrels: 1
• Class Rating: L
• Certification: UL Recognized, CSA Certified

Product Identification

• UPC: 78200199074
• GTIN: 00782001990749
