Cutler Hammer A201KCEA - 100A 3-Pole Molded Case Breaker (600V AC)
Cutler Hammer A201KCEA - 100A 3-Pole Molded Case Breaker (600V AC)

Cutler Hammer A201KCEA - 100A 3-Pole Molded Case Breaker (600V AC)

Cutler Hammer
Price
Save $3,566.11
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Cutler Hammer A201KCEA is a molded case circuit breaker designed for overcurrent protection and switching in industrial power distribution systems. It is rated for 600V AC maximum and carries a current rating of 100A, with a 14kAIC at 480V AC, and features a three-pole configuration with a thermal-magnetic trip mechanism. The unit measures 4.94 inches in depth, 5.06 inches in height, and 4.38 inches in width, weighing 4.5 lb, and is constructed with a metal frame and line/load terminal connections. This breaker complies with UL 489 standards and is suitable for use in panelboards, switchboards, and motor control centers. Typical applications include branch circuit protection, feeder protection, and equipment disconnection in commercial and industrial facilities.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, metal frame
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 4.94 in x 5.06 in x 4.38 in (Length/Depth x Height x Width)
  • Weight: 4.5 lb
  • Standards: UL 489
  • Applications: Branch circuit protection, feeder protection, equipment disconnection
  • Poles: 3
  • Trip Type: Thermal-magnetic
  • AIC Rating: 14kAIC at 480V AC
  • Connection: Line and load terminals
  • Frame Size: A201
  • Breaker Type: Molded case
  • Phase: 3
  • Hz: 50/60
  • Terminal Connection: Standard
  • Circuit Breaker Mounting Style: Fixed
  • Installation Type: Panelboard or switchboard
  • Enclosure: Open style


Product Identification
  • UPC: 78667881552
  • GTIN: 00786678815527
