Mersen A070URD30KI0125 - Square Body Fuse 125A (200kA@700V AC Interrupting Rating)

Mersen
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Mersen A070URD30KI0125 is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. This 125A rated fuse provides reliable overcurrent protection with a 700V AC voltage rating and features a compact square body construction with straight short blade connections for secure mounting. Engineered to UL/CSA standards, the fuse delivers 200kA interrupting capacity at 700V AC with ultra-rapid clearing characteristics for critical applications. Typical installations include motor control centers, industrial control panels, and power distribution equipment where high-performance circuit protection is essential.

Key Features & Specifications
  • Type: Current-limiting fuse, square body design with single barrel construction
  • Voltage Rating: 700V AC
  • Current Rating: 125A
  • Dimensions: Square body configuration with NA straight short blade connection
  • Standards: UL/CSA certified
  • Applications: Industrial power distribution, motor control centers, control panels
  • AIC rating: 200kA @ 700V AC
  • Class Rating: SB-0
  • Velocity: Ultra-rapid (UR) clearing characteristic
  • Barrels: 1
  • Connection: NA straight short blade
  • Weight: 5.19 lb
  • Family: PSC Square Body
  • Type: KI
  • Item Subcategory: Low Voltage


Product Identification
  • Manufacturer: Mersen
  • Model: A070URD30KI0125
