Mersen A055F1DSR0-150E - Medium Voltage Fuse 5500V/150A (63kA AIC)

Mersen A055F1DSR0-150E is a medium voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. It features a 5500V AC voltage rating and 150A current rating with a ferrule connection type, housed in a durable 3-inch diameter single-barrel construction rated for 63kA interrupting capacity at 5.5kV. The CS-3 series fuse meets Class E standards with 12-inch clip center spacing and 7 lb weight, complying with industrial protection requirements for medium-voltage switchgear, transformers, and motor circuits.

Key Features & Specifications

• Type: Current-limiting medium voltage fuse with silver-sand construction
• Voltage Rating: 5500V AC
• Current Rating: 150A
• Dimensions: 3" diameter, 12" clip center spacing
• Standards: Class E rating
• Applications: Medium-voltage switchgear, transformers, motor circuits
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Weight: 7 lb
• Family: CS-3 Series

Product Identification

• UPC: 78200180267
• GTIN: 00782001802677
