Mersen 9F60FJE100 - Medium Voltage Power Fuse 100A (Class E, 50kA AIC)

The Mersen 9F60FJE100 is a medium voltage power fuse designed for high-capacity circuit protection in industrial electrical systems. It features a 100A current rating and an 8250V voltage rating, providing robust overcurrent protection. The fuse is constructed as a single-barrel, Class E device with a 3-inch diameter and is engineered for use with 12-inch clip centers. It complies with industry standards for medium voltage applications and offers an interrupting rating of 50kA at 8.25kV. This fuse is typically applied in utility and industrial power distribution networks for protecting transformers, feeders, and motors.

Key Features & Specifications

• Type: Medium Voltage Power Fuse, EJO-1, Single Barrel
• Voltage Rating: 8250V
• Current Rating: 100A
• Dimensions: 3" Diameter, 12" Clip Center
• Standards: Class E
• Applications: Industrial power distribution, transformer and feeder protection
• AIC rating: [email protected]
• Family: 9F60 Series
• Barrels: 1
• Weight: 6 lb

Product Identification

• GTIN: 00782001397081
