Mersen 9F60DJH005 - Medium Voltage Fuse 5A 15.5kV (Class E 120kA AIC)
Mersen 9F60DJH005 - Medium Voltage Fuse 5A 15.5kV (Class E 120kA AIC)
Mersen 9F60DJH005 - Medium Voltage Fuse 5A 15.5kV (Class E 120kA AIC)
Mersen 9F60DJH005 - Medium Voltage Fuse 5A 15.5kV (Class E 120kA AIC)

Mersen 9F60DJH005 - Medium Voltage Fuse 5A 15.5kV (Class E 120kA AIC)

Mersen
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Mersen 9F60DJH005 is a medium voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 15.5kV voltage rating and 5A current rating, providing reliable overcurrent protection for medium voltage applications. The fuse construction utilizes a single-barrel design with 2-inch diameter and 12-inch clip center spacing, weighing 4 lb for straightforward installation in compatible fuse holders. This Class E rated fuse complies with industry standards for medium voltage protection and carries a 120kA interrupting rating at 15.5kV, ensuring dependable performance in demanding electrical environments. Typical applications include motor protection, transformer circuits, and feeder protection in industrial power systems where high fault current interruption is critical.

Key Features & Specifications
  • Type: Medium voltage current-limiting fuse, single barrel design
  • Voltage Rating: 15,500V AC
  • Current Rating: 5A
  • Dimensions: 2" diameter, 12" clip center spacing
  • Standards: Class E rated
  • Applications: Industrial power distribution, motor protection, transformer circuits
  • AIC rating: 120kA @ 15.5kV
  • Barrels: 1
  • Class Rating: E
  • Diameter: 2 inches
  • Clip Center: 12 inches
  • Weight: 4 lb
  • Family: 9F60 Series
  • Item Subcategory: Medium Voltage
