Mersen 9F60CJH002 - EJ-1 Medium Voltage Fuse 15.5kV 2A (82kA AIC)

Mersen 9F60CJH002 is a medium voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. This EJ-1 type fuse operates at 15.5kV with a 2A current rating and provides 82kA interrupting capacity at rated voltage. The single-barrel construction features a 2-inch diameter with 12-inch clip center spacing and weighs 5 lb, meeting Class E rating requirements for medium voltage applications. Compliant with industry standards for high-voltage protection, this fuse is typically deployed in utility substations, industrial power distribution, and medium voltage motor circuits where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: EJ-1 current-limiting fuse, single barrel construction
• Voltage Rating: 15500V AC
• Current Rating: 2A
• Dimensions: 2" diameter, 12" clip center spacing
• Standards: Class E rated for medium voltage applications
• Applications: Industrial power distribution, utility substations, medium voltage motor protection
• AIC rating: [email protected]
• Barrels: 1
• Class Rating: E
• Weight: 5 lb
• Item Subcategory: Medium Voltage
• Family: 9F60 Series

Product Identification

• GTIN: 00782001398101
