Mersen 9F60BDE905 - Class E Fuse 0.5A [email protected]

Mersen
Price
Save $136.23
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Mersen 9F60BDE905 is a medium-voltage current-limiting power fuse designed for the protection of transformers, motors, and capacitors in industrial power distribution systems up to 8.25 kV. It features a 0.5A current rating and a high interrupting capacity of 50 kA at its rated voltage, housed in a robust, single-barrel design with a 1.56-inch diameter and a 8.12-inch clip center dimension for secure mounting. Constructed as a Class E fuse, this unit provides reliable protection with a weight of 5 lb, ensuring compliance with industry standards for medium-voltage applications.

Key Features & Specifications
  • Type: Medium-voltage, current-limiting, single-barrel power fuse, Class E
  • Voltage Rating: 8250V
  • Current Rating: 0.5A
  • Dimensions: 1.56" diameter, 8.12" clip center
  • Standards: Class E rating
  • Applications: Protection for transformers, motors, and capacitors in industrial power systems
  • AIC rating: [email protected]
  • Barrels: 1
  • Weight: 5 lb


Product Identification
  • UPC: 078200139803
  • GTIN: 00782001398033
