Mersen 9F60BBD001 - Medium Voltage Fuse 1A 2750V (Class E 52kA AIC)

Mersen 9F60BBD001 is a medium voltage current-limiting fuse designed for industrial circuit protection applications. It features a 2750V voltage rating with a 1A current rating, providing reliable overcurrent protection in demanding electrical environments. The fuse construction includes a single-barrel design measuring 7.38 inches in length with a 1.56-inch diameter and 6-inch clip center spacing, weighing 5.19 lb for robust physical durability. This Class E rated fuse meets industry standards with an interrupting rating of 52kA at 2.75kV, ensuring compliance with medium voltage protection requirements. Typical applications include industrial power distribution systems, motor protection circuits, and medium voltage switchgear where precise current limitation is critical.

Key Features & Specifications

• Type: Medium Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 2750V
• Current Rating: 1A
• Dimensions: 7.38 in length, 1.56 in diameter
• Standards: Class E Rated
• Applications: Industrial power distribution, motor protection, medium voltage switchgear
• AIC rating: [email protected]
• Clip Center: 6 in
• Barrels: 1
• Class Rating: E
• Weight: 5.19 lb

Product Identification

• UPC: 78200139788
• GTIN: 00782001397883
