Square D 9998SAC62 - Magnetic Coil 600V 4000A (LSIGA Protection)
Square D 9998SAC62 - Magnetic Coil 600V 4000A (LSIGA Protection)

Square D 9998SAC62 - Magnetic Coil 600V 4000A (LSIGA Protection)

Square D
Price
Save $-18.87
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
The Square D 9998SAC62 is a magnetic coil designed for use in Schneider Electric motor control and power distribution equipment, providing the electromagnetic actuation for circuit breaker mechanisms. This coil operates within a 600V system and is rated for a continuous current of 4000A, supporting a 3-phase, 3-pole configuration with a draw-out connection. It features solid-state protection with LSIGA functions (Long-Time, Short-Time, Instantaneous, and Ground Fault Alarm) and an AIC rating of 100kA at 480V, housed in a compact unit measuring 2.2 x 3.2 x 2.2 inches and weighing 0.45 lb. This component is engineered for use in industrial switchgear and power distribution systems requiring precise overcurrent and ground fault alarm capabilities.

Key Features & Specifications
  • Type: Magnetic Coil
  • Voltage Rating: 600V
  • Current Rating: 4000A
  • Dimensions: 2.2 in (54.7 mm) x 3.2 in (81.5 mm) x 2.2 in (56.2 mm) (Height x Width x Depth)
  • Weight: 0.45 lb
  • Functions: LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm
  • Poles: 3
  • Connection: Draw-Out
  • Protection: Solid State
  • AIC rating: 100kA@480V
  • Phase: 3


Product Identification
  • UPC: 78590177097
  • GTIN: 00785901770978
