Square D 9080LBA361101 - Non-Automatic Disconnect, 2500A, 690V
Square D 9080LBA361101 - Non-Automatic Disconnect, 2500A, 690V

Square D 9080LBA361101 - Non-Automatic Disconnect, 2500A, 690V

Square D
Price
Save $-6.26
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D 9080LBA361101 is a non-automatic motor control part and accessory designed to serve as a disconnect or isolating switch in motor control circuits. It is rated for 690V AC, 2500A continuous current, and 80kA at 415V, with a 3-pole, 3-phase configuration and a bolt-on connection type. This compact unit measures 2.29 in x 2.12 in x 1.62 in and weighs 0.22 lb, constructed for panel mounting without integrated overcurrent protection. It is certified with CE Marking, CSA File 70361 Class 6228-1, and UL File E60616 Guide XCFR2, ensuring compliance with international safety standards. Typical applications include industrial motor control centers and switchgear where high-current isolation is required.

Key Features & Specifications
  • Type: Non-automatic motor control disconnect switch
  • Voltage Rating: 690V AC
  • Current Rating: 2500A
  • Poles: 3
  • Phase: 3
  • Connection: Bolt-On
  • Protection: Non-Automatic (No Overcurrent Protection)
  • AIC Rating: 80kA@415V
  • Functions: NA - No Overcurrent Protection
  • Dimensions: 2.29 in (58.17 mm) x 2.12 in (53.85 mm) x 1.62 in (41.15 mm) (Height x Width x Depth)
  • Weight: 0.22 lb
  • Certification: CE Marked, CSA File 70361 Class 6228-1, UL File E60616 Guide XCFR2
  • Country of Origin: United States


Product Identification
  • UPC: 785901097426
  • GTIN: 785901097426
