Schneider Electric 9012GRG5 - Pressure Switch 3-150 PSI SPDT 10A
Schneider Electric 9012GRG5 - Pressure Switch 3-150 PSI SPDT 10A

Schneider Electric 9012GRG5 - Pressure Switch 3-150 PSI SPDT 10A

Schneider Electric
Price
Save $-107.13
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Schneider Electric 9012GRG5 is an electromechanical pressure switch from the 9012G Series designed for reliable pressure monitoring and automation control. It features an adjustable threshold from 3 to 150 PSI with a fixed differential and a single-pole double-throw (SPDT) contact configuration rated for 10 amps at 480 volts AC. This switch weighs 2 lb and includes a 1/4 inch-18 TPI FNPT pressure connection port with screw-type electrical terminals, operating within an ambient temperature range of -10°F to 185°F. It is certified to CE, CSA C22.2, and UL 508 standards, ensuring compliance with industrial safety requirements. Typical applications include pressure monitoring in industrial automation systems, hydraulic and pneumatic control circuits, and process control equipment.

Key Features & Specifications
  • Type: Pressure Switch
  • Series: 9012G
  • Pressure Range: 3 to 150 PSI adjustable threshold
  • Contact Type: SPDT (Single-Pole Double-Throw)
  • Amperage Rating: 10A @ 480V AC
  • Pressure Connection: 1/4 inch-18 TPI FNPT
  • Max Line Pressure: 475 PSI
  • Electrical Connection: Screw terminals
  • Ambient Temperature Range: -10°F to 185°F
  • Mounting Type: Fixed scale pressure switch
  • Sensor Type: Electromechanical pressure switch
  • Weight: 2 lb
  • Certification: CE, CSA C22.2, UL 508
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901476528
  • GTIN: 00785901476528
