Telemecanique 9012GDW2 - Pressure Switch 10A 480VAC SPDT
Telemecanique 9012GDW2 - Pressure Switch 10A 480VAC SPDT

Telemecanique 9012GDW2 - Pressure Switch 10A 480VAC SPDT

Telemecanique
Price
Save $-114.19
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Telemecanique 9012GDW2 is an electromechanical pressure switch engineered for precise pressure monitoring and control in demanding industrial environments. This SPDT switch carries a contact rating of 10 A at 480 VAC, operates within a pressure range of 1 to 40 psi with a differential of 0.6 psi ±2.5% full scale, and features a zinc-plated steel connection with a 1/2-inch NPT conduit entry. Housed in a corrosion-resistant cast aluminum enclosure rated NEMA 4, 4X, and 13, the device measures 6.24 inches in height, 3.5 inches in width, and 2.63 inches in depth, weighing 3 lb. It is certified to CE, CSA C22.2, and RoHS standards, and offers mechanical durability up to 5 million cycles with shock resistance conforming to IEC 58-2-27. Typical applications include pressure monitoring in hydraulic and pneumatic systems, compressors, and industrial process control equipment.

Key Features & Specifications
  • Type: Pressure switch
  • Contact Configuration: SPDT (Single Pole Double Throw)
  • Contact Rating: 10 A at 480 VAC
  • Pressure Range: 1 to 40 psi
  • Differential: 0.6 psi ±2.5% Full Scale
  • Maximum Pressure: 100 psi
  • Enclosure Type: NEMA 4, 4X, 13
  • Housing Material: Cast Aluminum
  • Connection Material: Zinc Plated Steel
  • Cable Entry: 1/2 inch NPT conduit
  • Mechanical Durability: 5,000,000 cycles
  • Shock Resistance: 50 gn IEC 58-2-27
  • Operating Temperature: -10 to 185 °F
  • Dimensions: 6.24 in H x 3.5 in W x 2.63 in D
  • Weight: 3 lb
  • Certification: CE, CSA C22.2, RoHS
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901024903
  • GTIN: 00785901024903
