Telemecanique 9007AO1 is a snap-action limit switch from the 9007 family, designed for precise position sensing and motor control in industrial automation. It is rated for 600 VAC/VDC with a 15 Amp AC and 250mA DC current capacity, featuring a single-pole double-throw (SPDT) contact configuration with 1 normally open and 1 normally closed double break contacts. The switch is constructed with a heavy-duty cast zinc body and a round pin plunger actuator with spring return, measuring 0.83 in x 2.5" x 0.828" and weighing 0.09 lb, utilizing screw clamp terminal connections. It is certified to C22-2-14, CE, CSA, and UL Listed standards, ensuring compliance with industrial safety and performance requirements. Typical applications include limit switching, positioning, and interlocking in conveyor systems, machine tools, and other automated equipment.

Key Features & Specifications
  • Type: Snap switch
  • Voltage Rating: 600 VAC/VDC
  • Current Rating: 15 Amps AC, 250mA DC
  • Contact Configuration: SPDT (1NO + 1NC)
  • Actuator Type: Round Pin Plunger with Spring Return
  • Body Material: Cast Zinc
  • Terminal Type: Screw Clamp
  • Operation Type: Snap Action
  • Mounting Type: Panel or Surface Mount
  • Series: 9007
  • Country of Origin: Mexico
  • Dimensions: 0.83 in x 2.5" x 0.828"
  • Weight: 0.09 lb
  • Certification: C22-2-14, CE, CSA, UL Listed


Product Identification
  • UPC: 785901759034
  • GTIN: 00785901759034
