Square D 9001K2L38R20 - 30mm Push Button Operator 600V AC
Square D 9001K2L38R20 - 30mm Push Button Operator 600V AC

Square D 9001K2L38R20 - 30mm Push Button Operator 600V AC

Square D
Price
Save $-87.39
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D 9001K2L38R20 is a 30mm push button operator designed for industrial control panel applications requiring momentary actuation. This unit operates with a standard voltage rating of 600V AC and carries a continuous current rating of 10A, providing reliable switching for pilot duty circuits. The operator features a black flush head with a metal bezel and is constructed with durable thermoplastic materials, weighing 0.366 lb and manufactured in Mexico by Schneider Electric. It complies with multiple international standards including JIS C 852, JIS C 4520, EN/IEC 60947-5-4, EN/IEC 60947-1, CSA C22.2 No 14, UL 508, and EN/IEC 60947-5-1, ensuring global regulatory acceptance. This push button is commonly used in machine control stations, conveyor systems, and process control panels for start/stop or reset functions.

Key Features & Specifications
  • Type: 30mm momentary push button operator, black flush head, metal bezel
  • Voltage Rating: 600V AC
  • Current Rating: 10A
  • Weight: 0.366 lb
  • Standards: JIS C 852, JIS C 4520, EN/IEC 60947-5-4, EN/IEC 60947-1, CSA C22.2 No 14, UL 508, EN/IEC 60947-5-1
  • Applications: Machine control stations, conveyor systems, process control panels
  • Switch Type: Momentary push button
  • Configuration: Single pole, normally open
  • Enclosure: Open style, panel mount
  • Mounting: 30mm panel cutout
  • Terminal Connection: Screw clamp
  • Installation Type: Panel mount
  • Item QTY: 1


Product Identification
  • UPC: 785901900138
  • GTIN: 00785901900138
