Eaton 8NCLPT-2E-A - Medium Voltage Current-Limiting Power Fuse 2A 8300V (50kA AIC)

Eaton 8NCLPT-2E-A is a medium voltage current-limiting power fuse designed for circuit protection in industrial electrical systems. It features a 2A current rating and 8300V voltage rating with an interrupting capacity of 50kA at 8.3kV for reliable fault protection. The single-barrel construction measures 1.6 inches in diameter with 8.1-inch clip center spacing and weighs 2 lb, built to Class E specifications. This fuse complies with industry standards for medium voltage applications and is typically used in motor control centers, transformers, and feeder circuit protection where high-interrupting capacity is required.

Key Features & Specifications

• Type: NCLPT current-limiting power fuse, single barrel construction
• Voltage Rating: 8300V AC
• Current Rating: 2A
• Dimensions: 1.6-inch diameter, 8.1-inch clip center spacing
• Standards: Class E rated
• Applications: Motor control centers, transformer protection, feeder circuits
• AIC rating: [email protected]
• Barrels: 1
• Class Rating: E
• Diameter: 1.6 inches
• Clip Center: 8.1 inches
• Weight: 2 lb
• Family: CLPT

Product Identification

• GTIN: 00051712521833
