Eaton 8NCLPT-1E - Medium Voltage Fuse 1A 8.3kV (Class E)

Eaton
Price
Save $-920.60
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 8NCLPT-1E is a medium voltage current-limiting power fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 1A current rating and an 8.3kV voltage rating, with a high interrupting capacity of 50kA. The fuse is constructed as a single-barrel, Class E device with ferrule connections and a compact form factor measuring 5 inches in length with a 1.13-inch diameter. It is engineered and tested in compliance with IEEE Std. C37.41, ensuring reliable performance in demanding medium-voltage applications such as switchgear and motor control centers.

Key Features & Specifications
  • Type: NCLPT, Medium Voltage Current-Limiting Power Fuse, Single Barrel, Ferrule Connection
  • Voltage Rating: 8300V AC
  • Current Rating: 1A
  • Dimensions: 5 in L x 1.1 in H x 1.1 in W (127mm x 27.94mm x 27.94mm)
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection in Industrial Power Systems
  • AIC rating: 50kA @ 8.3kV
  • Class Rating: E
  • Diameter: 1.13 in (28.7 mm)
  • Clip Center: 4 in (101.6 mm)
  • Barrels: 1
  • Connection: Ferrule
  • Weight: 2 lb (0.91 kg)
  • Family: CLPT
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786670214847
  • GTIN: 00786670214847
