Eaton 8CX-4.5C - Medium Voltage Current-Limiting Fuse 4.5A (8300V, 50kA AIC)

Eaton 8CX-4.5C is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It features a 4.5A current rating and 8300V voltage rating with a high interrupting capacity of 50kA at 8.3kV for reliable circuit protection. The fuse utilizes a single-barrel construction with NX clip connection system, measuring 1.3 inches in diameter and featuring 10-inch clip center spacing while weighing 3 lb. This Class C rated fuse meets industry standards for medium voltage applications and is typically deployed in motor control centers, transformers, and feeder circuits where precise overcurrent protection is required.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse, single-barrel construction with NX clip connection
• Voltage Rating: 8300V AC
• Current Rating: 4.5A
• Dimensions: 1.3" diameter, 10" clip center spacing
• Standards: Class C rating
• Applications: Industrial power distribution, motor control centers, transformer protection, feeder circuits
• AIC rating: [email protected]
• Connection: NX Clip
• Barrels: 1
• Clip Center: 10 inches
• Class Rating: C
• Weight: 3 lb
