S&C Electric 86812R2 is a high-voltage SM-4 fuse holder designed for protecting electrical distribution systems up to 38kV. This rugged component features a 25 lb cast aluminum construction with corrosion-resistant hardware, meeting IEEE C37.40 standards for outdoor power equipment. Its dual-contact design ensures reliable current interruption while maintaining proper fuse alignment in switchgear applications. The unit is UL-listed and CSA-certified for industrial power systems, commonly deployed in utility substations and large commercial facilities requiring durable overcurrent protection.

Key Features & Specifications
  • Type: SM-4 fuse holder with cast aluminum body
  • Voltage Rating: 38kV maximum
  • Current Rating: 200A continuous
  • Dimensions: 12" x 8" x 6" (HxWxD)
  • Standards: IEEE C37.40, UL 248-12, CSA C22.2
  • Applications: Substation switchgear, industrial power distribution
  • Weight: 25 lb
  • Mounting: Vertical or horizontal panel installation
  • Material: Corrosion-resistant aluminum alloy
  • Terminals: Dual-pressure contact system
  • Insulation: Porcelain bushings with 100kV BIL rating
  • Environmental Rating: NEMA 3R for outdoor use
