S&C Electric 86642R2 - Distribution Class Fuse 15.5kV 200A (IEEE C37.40 Compliant)

S&C Electric 86642R2 is a high-voltage current-limiting fuse designed for protecting electrical distribution systems from short-circuit faults. Rated for 15.5 kV AC operation with a 200A continuous current rating, it features a durable silver-sand construction housed in a weather-resistant fiberglass tube. The fuse meets IEEE C37.40-2003 standards for distribution-class fuses and is commonly used in utility substations, industrial plants, and commercial power systems. Its compact design integrates with S&C's PMH fuse holders for secure mounting in switchgear applications.

Key Features & Specifications

• Type: Current-limiting power distribution fuse with silver-sand element
• Voltage Rating: 15.5 kV AC
• Current Rating: 200A continuous
• Dimensions: 25" length, 3.5" diameter
• Standards: IEEE C37.40-2003, UL 248-12
• Applications: Substation protection, industrial power distribution
• Weight: 25 lb
• Section: Fuse Holders
• Item Subcategory: Fuse Part And Accessory
• Construction: Fiberglass tube with stainless steel end caps
• Interrupting Rating: 50kA symmetrical
