S&C Electric 86152R2 - SM-5 High-Voltage Fuse 15.5kV/200A (IEEE C37.41 Compliant)
S&C Electric 86152R2 - SM-5 High-Voltage Fuse 15.5kV/200A (IEEE C37.41 Compliant)

S&C Electric 86152R2 - SM-5 High-Voltage Fuse 15.5kV/200A (IEEE C37.41 Compliant)

S&C Electric
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
S&C Electric 86152R2 is a high-voltage current-limiting fuse designed for protecting electrical distribution systems from short-circuit faults. Rated for 15.5kV AC systems with a 200A continuous current rating, this SM-5 class fuse features a rugged silver-sand construction housed in a weather-resistant fiberglass tube. It meets IEEE C37.41 standards for distribution-class fuses and is commonly used in utility substations, industrial plants, and commercial power systems. The fuse's 25 lb weight and bolt-on mounting design ensure secure installation in compatible fuse holders.

Key Features & Specifications
  • Type: Current-limiting expulsion fuse with silver-sand element
  • Voltage Rating: 15.5kV AC
  • Current Rating: 200A continuous
  • Dimensions: 25" length x 4" diameter (635mm x 102mm)
  • Standards: IEEE C37.41, UL 248-12
  • Applications: Substation protection, feeder circuits, transformer protection
  • Family: SM-5
  • Section: Fuse Holders
  • Weight: 25 lb (11.34 kg)
  • Construction: Fiberglass tube with weather-resistant finish
  • Interrupting Rating: 50kA symmetrical
