Square D 8502SEO1V08 - NEMA Contactor 90A 208VAC
Square D 8502SEO1V08 - NEMA Contactor 90A 208VAC

Square D 8502SEO1V08 - NEMA Contactor 90A 208VAC

Square D
Price
Save $-603.85
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D 8502SEO1V08 is a Schneider Electric NEMA Type S non-reversing contactor designed for motor control applications requiring reliable switching of loads with separate overload protection. This Size 3 contactor is rated for 90 amperes, 2 poles, and a 208 VAC coil operating at 60 Hz, with an interrupt capacity up to 100 kA for 1-phase systems. The open-style device measures 7.09 in (180.09 mm) in height, 5.47 in (138.94 mm) in width, and 6.50 in (165.10 mm) in depth, weighs 14 lb, and is constructed without an enclosure for panel mounting. It is UL Listed under file E78351 CCN NLDX and CSA Certified under LR60905 CLASS 3211 04, meeting stringent industry standards. Typical applications include controlling motors and other electrical loads in industrial environments where common control circuit wiring is employed.

Key Features & Specifications
  • Manufacturer: Schneider Electric
  • Type: NEMA Contactor, Type S
  • Amperage: 90 A
  • Poles: 2 Pole
  • Voltage: 208 VAC Coil, 1 Phase
  • Frequency: 60 Hz
  • Size/Frame: Size 3
  • Interrupt Rating: Up to 100 kA
  • Configuration: Nonreversing
  • Mounting: Open style (no enclosure)
  • Dimensions: 7.09 in (180.09 mm) x 5.47 in (138.94 mm) x 6.50 in (165.10 mm) (Height x Width x Depth)
  • Weight: 14 lb
  • Country of Origin: Mexico
  • Certification: CSA LR60905 CLASS 3211 04-UL LISTED FILE E78351 CCN NLDX


Product Identification
  • UPC: 785901475811
