Square D 8501XO1200V02 - Motor Control Accessory 1200A
Square D 8501XO1200V02 - Motor Control Accessory 1200A

Square D 8501XO1200V02 - Motor Control Accessory 1200A

Square D
Price
Save $-143.57
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
The Square D 8501XO1200V02 is a motor control accessory designed for instantaneous magnetic-only protection in industrial motor circuits. It operates at a voltage rating of 600V with a current rating of 1200A, supporting 3-phase systems and featuring a 65kA interrupting capacity at 480V. This 3-pole feed-thru connection unit accepts copper wire sizes from AWG 18 to AWG 12, weighs 2.93 lb, and measures 3.5 in (88.9 mm) in height, 2.23 in (56.64 mm) in width, and 6.36 in (161.54 mm) in depth. It is CSA Certified, RoHS Compliant, and UL Listed, making it suitable for heavy-duty industrial applications requiring reliable overcurrent protection.

Key Features & Specifications
  • Type: Motor Control Part And Accessory
  • Voltage Rating: 600V
  • Current Rating: 1200A
  • Dimensions: 3.5 in (88.9 mm) x 2.23 in (56.64 mm) x 6.36 in (161.54 mm) (Height x Width x Depth)
  • Standards: CSA Certified, RoHS Compliant, UL Listed
  • Applications: Industrial motor control and protection
  • Poles: 3
  • Connection: Feed-Thru
  • Protection: Magnetic Only
  • Wire Size: AWG 18...AWG 12 copper
  • AIC rating: 65kA@480V
  • Phase: 3
  • Functions: I - Instantaneous
  • Weight: 2.93 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 078590153686
  • GTIN: 00785901536864
