Allen-Bradley 800H2HA7 - Motor Circuit Protector 2A 600V AC
Allen-Bradley 800H2HA7 - Motor Circuit Protector 2A 600V AC

Allen-Bradley 800H2HA7 - Motor Circuit Protector 2A 600V AC

Allen-Bradley
Price
Save $-415.91
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Allen-Bradley 800H2HA7 is a heavy-duty motor control circuit breaker designed to provide reliable overload and short-circuit protection for industrial motor circuits. It features a 600V AC voltage rating and a 2A current rating, housed within a robust, compact frame constructed for durability in demanding environments. This unit complies with key industry standards including UL and CSA, ensuring safe operation across various applications. It is typically employed for the protection of control circuits, small motors, and transformers within industrial panels and machinery.

Key Features & Specifications
  • Type: Thermal-magnetic circuit breaker, manual motor protector
  • Voltage Rating: 600V AC
  • Current Rating: 2A
  • Dimensions: Compact frame size
  • Standards: UL, CSA
  • Applications: Motor circuit protection, control circuit protection, transformer protection
  • Switch Type: Toggle
  • Configuration: 1-pole
  • Phase: Single
  • Amperage: 2A
  • AIC Rating: 5kA at 240V AC, 2kA at 480V AC
  • Connection: Screw terminal
  • Poles: 1
  • Protection: Thermal overload, magnetic short-circuit
  • Functions: Manual ON/OFF, trip indication
  • Frame Size: Compact
  • Trip Type: Fixed
  • Mounting: DIN rail or panel mount
  • Hz: 50/60 Hz
  • Horse Power: 0.33 HP at 240V AC, 0.5 HP at 480V AC
  • Full Load Amps: 2A
  • Enclosure: Open style
  • Wire Size: #14-8 AWG
  • Certification: cULus Listed
  • Terminal Connection: Screw clamp
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single
  • Standards: UL 489, CSA C22.2 No. 5
  • Installation Type: DIN rail or panel
  • Item QTY: 1
  • Breaker Frame: Compact
  • Operating Temperature Maximum Celsius: 60°C
  • Weight: 5.19 lb


Product Identification
  • Manufacturer: Allen-Bradley
  • Model: 800H2HA7
  • Item Subcategory: Part And Accessory
