Eaton 7BCLS-3R - Medium Voltage Fuse 100A (7200V, 50kA AIC)

Eaton
Price
Save $1,377
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 7BCLS-3R is a medium voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power distribution systems. It features a 7200V AC voltage rating and a 100A current rating, providing high interrupting capacity for reliable circuit protection. The fuse is constructed as a single-barrel, bolt-on unit with a diameter of 3 inches and a length of 19.25 inches, weighing 10 lb for robust mechanical integration. It complies with the IEEE Std. C37.41 standard and carries a Class R rejection rating to ensure non-interchangeability with lower-capacity fuses. Typical applications include safeguarding medium voltage equipment within utility, industrial, and commercial electrical infrastructures.

Key Features & Specifications
  • Type: Medium Voltage, Current-Limiting, Single Barrel, Bolt-On Fuse
  • Voltage Rating: 7200V AC
  • Current Rating: 100A
  • Dimensions: 19.25 in L x 3.6 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection
  • Class Rating: R
  • AIC rating: 50kA @ 7.2kV
  • Connection: Bolt-On
  • Barrels: 1
  • Diameter: 3 in
  • Weight: 10 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782114893753
  • GTIN: 00782114893753
