Eaton 6DSL-D3000 - Class R Fuse 200kA@600V (IEEE C37.41)
6DSL-D3000 Eaton Low Voltage Fuse 600V Fuse - Essential Electric Supply
6DSL-D3000 Eaton Low Voltage Fuse 600V Fuse - Essential Electric Supply
6DSL-D3000 Eaton Low Voltage Fuse 600V Fuse - Essential Electric Supply
Eaton 6DSL-D3000 - Class R Fuse 200kA@600V (IEEE C37.41)

Eaton 6DSL-D3000 - Class R Fuse 200kA@600V (IEEE C37.41)

Eaton
Price
Save $4,548.33
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 6DSL-D3000 is a Class R low-voltage current-limiting fuse designed for high-interrupting capacity protection in industrial power distribution systems. It features a 600V AC voltage rating and provides a 200kA interrupting rating at 600V AC to safely clear high-level faults. The fuse is constructed with a single-barrel design, measures 5.75 in (L) x 4.25 in (H) x 4.25 in (W), has a 3-inch diameter, and weighs 6.4 lb. It is engineered and tested to comply with the IEEE Std. C37.41 standard, ensuring reliable performance in demanding applications such as service entrance equipment, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Class R, low-voltage, current-limiting fuse with single-barrel construction
  • Voltage Rating: 600V AC
  • Interrupting Rating (AIC): 200kA @ 600V AC
  • Dimensions: 5.75 in (Length) x 4.25 in (Height) x 4.25 in (Width)
  • Weight: 6.4 lb
  • Diameter: 3 in
  • Standards: Certified to IEEE Std. C37.41
  • Class Rating: R
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 78667024993
  • GTIN: 00786670249931
