Littelfuse 65E2C15.5 - E-Rated Medium Voltage Fuse 65A ([email protected] AIC)

Littelfuse 65E2C15.5 is an E-Rated medium voltage fuse from the Powr-Gard family, engineered to provide reliable overcurrent protection for high-power electrical systems. It features a 65A current rating and a 15.5kV voltage rating, capable of interrupting up to 80kA fault currents. The fuse is constructed with a robust two-barrel design, measures 3 inches in diameter with a 15-inch clip center spacing, and weighs 26 lb for secure installation. This fuse complies with industry standards for E-Rated classification, ensuring consistent performance in demanding industrial environments. Typical applications include protection for transformers, motors, and feeders in medium voltage distribution systems.

Key Features & Specifications

• Type: E-Rated medium voltage fuse, two-barrel construction
• Voltage Rating: 15.5kV
• Current Rating: 65A
• Dimensions: 3" diameter, 15" clip center
• Standards: E-Rated classification
• Applications: Transformer, motor, and feeder protection in medium voltage systems
• AIC rating: [email protected]
• Class Rating: E
• Barrels: 2
• Weight: 26 lb

Product Identification

• UPC: 079458041248
• GTIN: 00079458041248
