Siemens 5SY62327 - Molded Case Circuit Breaker 32A 400V
Siemens 5SY62327 - Molded Case Circuit Breaker 32A 400V

Siemens 5SY62327 - Molded Case Circuit Breaker 32A 400V

Siemens
Price
Save $77.26
/
Condition
  • Low stock - 8 items left
  • Backordered, shipping soon
Call for Price
Siemens 5SY62327 is a 2-pole molded case circuit breaker from the 5SY Series, designed for overcurrent and short-circuit protection in industrial and commercial applications. It provides thermal-magnetic protection with LI (Long-Time and Instantaneous) functions, rated at 400V AC with a 6kA interrupting capacity at 400V. The unit features a feed-thru connection, measures 3.622 x 1.575 x 3.307 inches, and weighs 0.681 lb. Manufactured in Germany, it complies with EN 60898 standards and is suitable for installation in control panels and distribution boards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker
  • Manufacturer: Siemens
  • Family: 5SY Series
  • Country of Origin: Germany
  • Dimensions: 3.622 x 1.575 x 3.307 inch
  • Weight: 0.681 lb
  • Functions: LI - Long-Time and Instantaneous
  • Voltage Rating: 400V
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • AIC rating: 6kA@400V
  • Amperage Rating: 32 A
  • Number of Poles: 2
  • Trip Curve: C-Curve
  • Breaking Capacity: 6 kA (EN 60898)
  • Frequency: 50/60 Hz
  • Protection Class: IP20 with connected conductors
  • Conductor Cross-Section: 0.75 mm² to 35 mm² (solid)


Product Identification
  • UPC: 66264378699
  • GTIN: 00662643786996
