Eaton 5NCLPT-1E - Medium Voltage Fuse 1A 5500V (63kA AIC)

Eaton
Price
Save $-59.12
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5NCLPT-1E is a medium voltage current-limiting power fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 5500V AC voltage rating and a 1A continuous current rating, housed within a compact, single-barrel ferrule connection design measuring 143 mm in length with a 20.6 mm diameter. The fuse is constructed to meet IEEE Std. C37.41 and provides an interrupting rating of 63kA at 5.5kV, ensuring reliable protection for medium voltage applications requiring a Class E rating.

Key Features & Specifications
  • Type: NCLPT, Medium Voltage Current-Limiting Power Fuse, Ferrule Connection, Single Barrel
  • Voltage Rating: 5500V AC
  • Current Rating: 1A
  • Dimensions: 143 mm (Length) x 20.6 mm (Height) x 20.6 mm (Width)
  • Weight: 0.253 lb
  • Diameter: 0.81 in
  • Class Rating: E
  • AIC Rating: 63kA @ 5.5kV
  • Certification: IEEE Std. C37.41
  • Connection: Ferrule
  • Barrels: 1
  • Country of Origin: United States


Product Identification
  • UPC: 078211461010
  • GTIN: 00782114610107
