Bussmann 5MCLS-9R-A - Medium Voltage Current-Limiting Fuse 200A (50kA AIC @ 4.8kV)

Bussmann 5MCLS-9R-A is a medium voltage current-limiting fuse designed for protecting electrical distribution systems from short-circuit faults. It features a 4800V voltage rating and 200A current rating with a 50kA interrupting capacity at 4.8kV. The fuse construction includes a single-barrel design with 3-inch diameter and bolt-in connection type, measuring 16.5 inches in length with 19.2-inch clip center spacing. Certified to IEEE Std. C37.41 standards, this Class R fuse provides reliable protection for industrial power distribution equipment and medium voltage applications requiring high interrupting capacity.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse, single barrel, bolt-in connection
• Voltage Rating: 4800V AC
• Current Rating: 200A
• Dimensions: 16.5" L × 32.02" H × 23" W
• Standards: IEEE Std. C37.41
• Applications: Industrial power distribution, medium voltage protection
• Switch Type: Not applicable
• Configuration: Single unit
• Diameter: 3 inches
• Class Rating: R
• AIC rating: [email protected]
• Connection: Bolt In
• Barrels: 1
• Clip Center: 19.2 inches
• Weight: 4.25 lb
• Family: Limitamp
• Country of Origin: United States

Product Identification

• UPC: 786685409245
• GTIN: 00786685409245
