Bussmann 5MCLS-6R-B - MCLS Fuse 170A 4800V (Class R)

Bussmann
Price
Save $-2,017.11
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 5MCLS-6R-B is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It provides a 170A current rating and a 4800V voltage rating, with a high interrupting capacity of 50kA at 4.8kV. The fuse features a single-barrel, bolt-in construction with a diameter of 3 inches, a length of 18.75 inches, and a clip center spacing of 19.2 inches, weighing 10 lb. It is engineered to comply with the IEEE Std. C37.41 standard and is typically applied in motor circuits, transformers, and feeder protection where a Class R rejection characteristic is required.

Key Features & Specifications
  • Type: MCLS, Medium Voltage Current-Limiting Fuse, Single Barrel
  • Voltage Rating: 4800V AC
  • Current Rating: 170A
  • Dimensions: 18.75 in L x 4.47 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Industrial motor, transformer, and feeder protection
  • Class Rating: R
  • AIC rating: 50kA @ 4.8kV
  • Connection: Bolt In
  • Clip Center: 19.2 in
  • Diameter: 3 in
  • Weight: 10 lb
  • Country of Origin: United States


Product Identification
  • UPC: 051712532617
  • GTIN: 00786685409337
