Eaton 5MCLS-2R-A - MCLS Fuse 70A 4800V (Class R)

Eaton
Price
Save $-231.03
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5MCLS-2R-A is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It provides a 70A current rating and a 4800V voltage rating, with a high interrupting capacity of 50kA at 4.8kV. The fuse features a single-barrel, bolt-in construction with a 3-inch diameter and an overall length of 18.75 inches, weighing 10 lb, and is engineered to a 19.2-inch clip center spacing. It complies with the IEEE Std. C37.41 standard and carries a Class R rating for rejection of lower-class fuses, ensuring safe application in medium-voltage motor circuits, transformers, and feeder protection.

Key Features & Specifications
  • Type: MCLS, Medium Voltage Current-Limiting Fuse, Single Barrel, Bolt-In Connection
  • Voltage Rating: 4800V
  • Current Rating: 70A
  • Dimensions: 18.75 in L x 4.47 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Industrial power distribution, motor protection, transformer protection, feeder protection
  • AIC rating: 50kA @ 4.8kV
  • Class Rating: R
  • Diameter: 3 in
  • Clip Center: 19.2 in
  • Barrels: 1
  • Connection: Bolt In
  • Weight: 10 lb


Product Identification
  • UPC: 786685409191
  • GTIN: 00786685409191
