Bussmann 5MCLS-24R-B - Medium Voltage Fuse 450A 4800V (50kA AIC)

Bussmann
Price
Save $-3,306.61
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 5MCLS-24R-B is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It features a 4800V AC voltage rating and a 450A current rating, providing high interrupting capacity for demanding applications. The fuse is constructed with a two-barrel design, measures 18.75 inches in length with a 3-inch diameter, and utilizes a bolt-in connection for secure installation. It complies with IEEE Std. C37.41 and is engineered for use in motor control centers, transformers, and feeder circuits where a 50kA symmetrical interrupting rating at 4.8kV is required.

Key Features & Specifications
  • Type: MCLS (Medium Voltage Current-Limiting) fuse, two-barrel design
  • Voltage Rating: 4800V AC
  • Current Rating: 450A
  • Dimensions: 18.75 in L x 7 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Industrial power distribution, motor protection, transformer protection
  • AIC rating: 50kA @ 4.8kV
  • Class Rating: R
  • Connection: Bolt In
  • Clip Center: 19.2 in
  • Diameter: 3 in
  • Weight: 20 lb
  • Country of Origin: United States


Product Identification
  • UPC: 786685409375
