Bussmann 5MCLS-24R-A - Medium Voltage Current-Limiting Fuse 450A

Bussmann
Price
Save $-70.34
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Bussmann 5MCLS-24R-A is a medium-voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 4800V AC voltage rating and a 450A continuous current rating, housed within a robust two-barrel construction measuring 18.75 inches in length with a 3-inch diameter and a 19.2-inch clip center spacing for bolt-in connection. Manufactured to IEEE Std. C37.41, this Class R fuse provides a 50kA interrupting rating at 4.8kV to ensure reliable protection against high fault currents. Its design is suited for demanding applications in utility and industrial switchgear, motor control centers, and transformer protection.

Key Features & Specifications
  • Type: MCLS, Medium Voltage Current-Limiting Fuse, Two-Barrel Construction
  • Voltage Rating: 4800V AC
  • Current Rating: 450A
  • Dimensions: 18.75 in L x 7 in H x 3 in W
  • Standards: Certified to IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection in Industrial Power Systems
  • Class Rating: R
  • AIC rating: 50kA @ 4.8kV
  • Connection: Bolt In
  • Barrels: 2
  • Clip Center: 19.2 in
  • Diameter: 3 in
  • Weight: 20 lb


Product Identification
  • UPC: 786685409276
