Eaton 5LCLS-6R - Medium Voltage Fuse 5500V 170A (50kA AIC @5.5kV)

Eaton 5LCLS-6R is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 5500V AC operation with a 170A current rating, it features a single-barrel construction with a 3-inch diameter and 14-inch clip center spacing for standardized mounting. The fuse complies with IEEE Std. C37.41 and delivers 50kA interrupting capacity at 5.5kV, making it suitable for transformer protection, motor circuits, and feeder protection in utility and industrial applications.

Key Features & Specifications

• Type: LCLS (Low Peak Current-Limiting) medium-voltage fuse with Class R rating
• Voltage Rating: 5500V AC
• Current Rating: 170A
• Dimensions: 3" diameter, 14" clip center spacing
• Standards: IEEE Std. C37.41
• Applications: Transformer protection, motor circuits, industrial feeders
• AIC rating: [email protected]
• Barrels: 1
• Weight: 7.2 lb
• Country of Origin: Dominican Republic

Product Identification

• UPC: 786670150770
• GTIN: 00786670150770
