Eaton 5LCLS-5R - Class R Current-Limiting Fuse 5500V 150A (50kA AIC)

Eaton 5LCLS-5R is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. It features a 5500V AC rating with a 150A current capacity and 50kA interrupting capability at 5.5kV, housed in a durable single-barrel construction with 3-inch diameter and 14-inch clip center spacing. Certified to IEEE Std. C37.41, this Class R fuse meets stringent industry standards for medium-voltage applications. Typical uses include transformer protection, motor starters, and feeder circuits in utility and industrial power distribution systems.

Key Features & Specifications

• Type: LCLS current-limiting fuse with silver-sand construction
• Voltage Rating: 5500V AC
• Current Rating: 150A
• Dimensions: 3" diameter, 14" clip center
• Standards: IEEE Std. C37.41 compliant
• Applications: Transformer/motor protection, industrial feeders
• AIC rating: [email protected]
• Class Rating: R
• Barrels: 1
• Weight: 3.6 lb

Product Identification

• UPC: 786670150763
• GTIN: 00786670150763
