Eaton 5CLS-12R - Medium Voltage Fuse 230A 5.5kV (50kA AIC)

Eaton
Price
Save $1,936.02
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5CLS-12R is a medium-voltage current-limiting fuse designed for protecting transformers, motors, and feeders in industrial power systems. It is rated for 5.5 kV systems with a continuous current rating of 230A and an interrupting rating of 50 kA at 5.5 kV. The fuse features a robust two-barrel construction with a 3-inch diameter and a 12-inch clip center spacing, housed within a compact form factor measuring 15.9 x 3 x 3 inches and weighing 8 lb. Manufactured in the United States, it complies with IEEE Std. C37.41, ensuring reliable performance and protection for medium-voltage switchgear and motor starters.

Key Features & Specifications
  • Type: Medium-voltage current-limiting fuse, two-barrel construction
  • Voltage Rating: 5500V
  • Current Rating: 230A
  • Dimensions: 15.9 in x 3 in x 3 in (L x H x W)
  • Standards: IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and feeders in industrial power systems
  • Class Rating: R
  • AIC rating: [email protected]
  • Clip Center: 12 in
  • Barrels: 2
  • Diameter: 3 in
  • Weight: 8 lb
  • Country of Origin: United States


Product Identification
  • UPC: 786670221845
  • GTIN: 00786670221845
