Bussmann 5CLE1-80E - Class E Current-Limiting Fuse 80A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-80E - Class E Current-Limiting Fuse 80A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-80E - Class E Current-Limiting Fuse 80A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-80E - Class E Current-Limiting Fuse 80A (65kA AIC @ 5.5kV)

Bussmann 5CLE1-80E - Class E Current-Limiting Fuse 80A (65kA AIC @ 5.5kV)

Bussmann
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 5CLE1-80E is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It features a 5500V AC voltage rating and an 80A current rating, providing reliable overcurrent protection. The fuse is constructed with a single-barrel ferrule connection design, measures 3 inches in diameter with a 14-inch clip center spacing, and has a robust build weighing 10 lb. It complies with Class E fuse standards and is rated for an interrupting capacity of 65kA at 5.5kV. This fuse is typically applied in motor control centers, transformers, and feeder circuits requiring high-interrupting capacity protection.

Key Features & Specifications
  • Type: CLE-1 current-limiting fuse with ferrule connection, single barrel construction
  • Voltage Rating: 5500V AC
  • Current Rating: 80A
  • Dimensions: 3" diameter, 14" clip center spacing
  • Standards: Class E fuse rating
  • Applications: Industrial power distribution, motor control centers, transformer protection
  • AIC rating: [email protected]
  • Connection: Ferrule
  • Barrels: 1
  • Weight: 10 lb
  • Class Rating: E
