Bussmann 5CLE1-225E - Class E Medium Voltage Fuse 225A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-225E - Class E Medium Voltage Fuse 225A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-225E - Class E Medium Voltage Fuse 225A (65kA AIC @ 5.5kV)
Bussmann 5CLE1-225E - Class E Medium Voltage Fuse 225A (65kA AIC @ 5.5kV)

Bussmann 5CLE1-225E - Class E Medium Voltage Fuse 225A (65kA AIC @ 5.5kV)

Bussmann
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 5CLE1-225E is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power systems. It features a 5500V AC voltage rating and a 225A current rating, providing reliable overcurrent protection. The fuse is constructed with a single-barrel ferrule connection design, measures 3 inches in diameter with a 14-inch clip center spacing, and has a robust build weighing 10 lb. It complies with Class E fuse standards and is certified for interrupting ratings up to 65kA at 5.5kV. Typical applications include motor circuits, transformers, and feeder protection in industrial facilities.

Key Features & Specifications
  • Type: CLE-1 current-limiting fuse, single barrel, ferrule connection
  • Voltage Rating: 5500V AC
  • Current Rating: 225A
  • Dimensions: 3" diameter, 14" clip center
  • Standards: Class E fuse rating
  • Applications: Industrial motor protection, transformer circuits, feeder protection
  • AIC rating: [email protected]
  • Connection: Ferrule
  • Barrels: 1
  • Weight: 10 lb
  • Class Rating: E
  • Item Subcategory: Medium Voltage
