Bussmann 5CLE1-125E - Class E Fuse 125A 5500V (65kA Interrupting Rating)

Bussmann
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 5CLE1-125E is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power systems. It features a 125A current rating and a 5500V voltage rating, providing reliable circuit interruption. The fuse is constructed with a single-barrel ferrule connection, measures 3 inches in diameter with a 14-inch clip center, and has a robust design weighing 10 lb. It complies with Class E fuse standards and offers an interrupting rating of 65kA at 5.5kV for high-fault current protection. Typical applications include motor control centers, transformers, and feeder circuits in industrial facilities.

Key Features & Specifications
  • Type: CLE-1 current-limiting fuse, single barrel construction with ferrule connection
  • Voltage Rating: 5500V AC
  • Current Rating: 125A
  • Dimensions: 3" diameter, 14" clip center
  • Standards: Class E fuse rating
  • Applications: Industrial power systems, motor control centers, transformer protection
  • AIC rating: [email protected]
  • Connection: Ferrule
  • Barrels: 1
  • Class Rating: E
  • Weight: 10 lb
