Eaton 5BHLE-50E - Medium Voltage Fuse 50A 5500V (63kA AIC)

Eaton
Price
Save $1,282.42
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BHLE-50E is a medium voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 50A current rating and a 5500V voltage rating, housed in a robust single-barrel construction measuring 19.25 inches in length with a 3-inch diameter and a 12-inch clip center spacing. The fuse is certified to IEEE Std. C37.41 and provides a high interrupting capacity of 63kA at 5.5kV, ensuring reliable protection for medium-voltage circuits against short-circuit faults.

Key Features & Specifications
  • Type: BHLE medium voltage current-limiting fuse, single barrel
  • Voltage Rating: 5500V
  • Current Rating: 50A
  • Dimensions: 19.25 in L x 3.6 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and feeders
  • AIC rating: [email protected]
  • Class Rating: E
  • Diameter: 3 in
  • Clip Center: 12 in
  • Barrels: 1
  • Weight: 9 lb


Product Identification
  • UPC: 782116072927
