Eaton 5BHLE-20E - Medium Voltage Fuse 20A 5500V (63kA AIC)

Eaton
Price
Save $1,282.42
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BHLE-20E is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It provides a 20A current rating and a 5500V voltage rating for reliable circuit interruption, constructed as a single-barrel fuse with a 3-inch diameter and overall dimensions of 19.25 in x 3.6 in x 3 in. The fuse is engineered to meet IEEE Std. C37.41 and offers an interrupting rating of 63kA at 5.5kV, ensuring protection for transformers, motors, and capacitor banks in demanding applications.

Key Features & Specifications
  • Type: BHLE medium voltage current-limiting fuse, single barrel construction
  • Voltage Rating: 5500V
  • Current Rating: 20A
  • Dimensions: 19.25 in (L) x 3.6 in (H) x 3 in (W)
  • Standards: Certified to IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and capacitor banks in industrial power systems
  • AIC rating: 63kA @ 5.5kV
  • Class Rating: E
  • Barrels: 1
  • Diameter: 3 inches
  • Clip Center: 12
  • Weight: 9 lb


Product Identification
  • UPC: 782116073238
  • GTIN: 00782116073238
