Eaton 5BCLS-9R - Medium Voltage Fuse 200A 5080V (50kA AIC)

Eaton
Price
Save $-741.85
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BCLS-9R is a medium-voltage current-limiting fuse designed for high-interrupting capacity protection in industrial power distribution systems. It features a 200A current rating and a 5080V voltage rating, engineered to safely interrupt fault currents up to 50kA. The fuse is constructed as a single-barrel, bolt-on unit with a 3-inch diameter and overall dimensions of 19.25 in x 3.6 in x 3 in, weighing 10 lb. It complies with the IEEE Std. C37.41 standard and is typically applied for the protection of transformers, capacitors, and feeders in medium-voltage switchgear and motor circuits.

Key Features & Specifications
  • Type: BCLS, Medium Voltage Current-Limiting Fuse, Single Barrel
  • Voltage Rating: 5080V
  • Current Rating: 200A
  • Dimensions: 19.25 in L x 3.6 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Capacitor, and Feeder Protection
  • Class Rating: R
  • AIC rating: 50kA @ 5.08kV
  • Connection: Bolt-On
  • Diameter: 3 in
  • Weight: 10 lb
  • Country of Origin: United States


Product Identification
  • UPC: 782114893692
  • GTIN: 00782114893692
