Eaton 5BCLS-5R - Medium Voltage Fuse 150A @ 5080V (R-Class)

Eaton
Price
Save $-620.99
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BCLS-5R is a medium-voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 150A current rating and a 5080V voltage rating, housed within a robust single-barrel construction with a 3-inch diameter and bolt-on connection terminals for secure installation. The fuse is engineered to IEEE Std. C37.41 and provides an interrupting rating of 50kA at 5.08kV, ensuring reliable protection against high-level fault currents. Its R-class time-current characteristic makes it suitable for applications requiring precise coordination within medium-voltage switchgear and motor starters.

Key Features & Specifications
  • Type: BCLS, Medium Voltage Current-Limiting Fuse, Single Barrel
  • Voltage Rating: 5080V
  • Current Rating: 150A
  • Dimensions: 19.25 in L x 3.6 in H x 3 in W
  • Weight: 10 lb
  • Diameter: 3 in
  • Class Rating: R
  • Connection: Bolt-On
  • Barrels: 1
  • Standards: IEEE Std. C37.41
  • AIC Rating: 50kA @ 5.08kV
  • Applications: Transformer, Motor, and Feeder Protection
  • Family: CLS
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782114893661
  • GTIN: 00782114893661
