Eaton 5BCLS-4R - Medium Voltage Fuse 130A (Class R, 50kA AIC)

Eaton
Price
Save $1,665.59
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BCLS-4R is a medium-voltage current-limiting fuse designed for high-interrupting capacity protection in industrial power distribution systems. It provides a 130A current rating and a 5080V voltage rating for robust circuit protection, housed in a single-barrel, bolt-on construction measuring 19.25 in long with a 3 in diameter and a weight of 10 lb. The fuse is certified to IEEE Std. C37.41 and features a Class R rating with an interrupting rating of 50kA at 5.08kV, ensuring reliable performance in demanding applications such as motor control centers, transformers, and feeder circuits.

Key Features & Specifications
  • Type: BCLS, Medium Voltage Current-Limiting Fuse, Single Barrel
  • Voltage Rating: 5080V
  • Current Rating: 130A
  • Dimensions: 19.25 in x 3.6 in x 3 in (L x H x W)
  • Diameter: 3 in
  • Weight: 10 lb
  • Class Rating: R
  • Connection: Bolt-On
  • Barrels: 1
  • AIC Rating: 50kA @ 5.08kV
  • Standards: IEEE Std. C37.41
  • Applications: Industrial power distribution, motor protection, transformer protection
  • Family: CLS
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782114893678
  • GTIN: 00782114893678
