Eaton 5BCLS-3R - Class R Medium Voltage Fuse 100A 5080V

Eaton
Price
Save $-408.53
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BCLS-3R is a medium-voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 100A current rating and a 5080V voltage rating, with a high interrupting capacity of 50kA. The fuse is constructed with a single-barrel design, a 3-inch diameter, and a bolt-on connection, housed in a unit measuring 19.25 in x 3.6 in x 3 in and weighing 10 lb. It complies with the IEEE Std. C37.41 standard and is classified as a Class R fuse, providing rejection of lower-class fuseholders for enhanced safety. Typical applications include medium-voltage switchgear, motor starters, and transformer protection circuits.

Key Features & Specifications
  • Type: BCLS, Medium Voltage Current-Limiting Fuse, Single Barrel
  • Voltage Rating: 5080V
  • Current Rating: 100A
  • Dimensions: 19.25 in (L) x 3.6 in (H) x 3 in (W)
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection
  • Class Rating: R
  • AIC Rating: 50kA @ 5.08kV
  • Connection: Bolt-On
  • Diameter: 3 in
  • Weight: 10 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782116122257
  • GTIN: 00782116122257
