Bussmann 5BCLS-12R - Medium Voltage Current-Limiting Fuse 230A 5080V (Class R, 50kA AIC)
Regular price
$3,228.21
$3,228.21
Regular price
$2,517.65
$2,517.65
Sale price
$3,228.21
$3,228.21
Save $-710.56
/
- In stock, ready to ship
- Backordered, shipping soon
The Bussmann 5BCLS-12R is a medium voltage current-limiting fuse designed for high-interrupting capacity protection in industrial power systems. It features a 5080V voltage rating and a 230A current rating, providing reliable circuit protection under demanding conditions. The fuse is constructed with a single-barrel design measuring 15.9 inches in length with a 3-inch diameter and features bolt-on connections for secure installation. Certified to IEEE Std. C37.41 standards, this Class R fuse offers 50kA interrupting capacity at 5.08kV and is commonly used in motor control centers, switchgear, and industrial power distribution systems where high fault current protection is required.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Medium voltage current-limiting fuse, single barrel construction
- Voltage Rating: 5080V
- Current Rating: 230A
- Dimensions: 15.9" L × 3" W × 3" H
- Standards: IEEE Std. C37.41
- Applications: Industrial power distribution, motor control centers, switchgear
- Class Rating: R
- Connection: Bolt-On
- Barrels: 1
- AIC rating: [email protected]
- Diameter: 3 inches
- Weight: 5.25 lb
- Family: CLS
- Country of Origin: Dominican Republic
Product Identification
- UPC: 051712528092
- GTIN: 00782114893708
