Bussmann 5ACLS-9R - Medium Voltage Current-Limiting Fuse 200A (Class R, 5080V)

Bussmann 5ACLS-9R is a medium voltage current-limiting fuse designed for protecting electrical distribution systems and equipment from short-circuit faults. It features a 5080V AC voltage rating with a 200A current rating and provides 50kA interrupting capacity at 5.08kV. The fuse construction includes a single-barrel design with ferrule connections, measuring 15.9 inches in length with a 3-inch diameter and weighing 5.9 pounds. This Class R fuse complies with IEEE Std. C37.41 standards and is typically applied in industrial power distribution systems, motor circuits, and transformer protection applications where high fault current interruption is required.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse, single-barrel construction with ferrule connections
• Voltage Rating: 5080V AC
• Current Rating: 200A
• Dimensions: 15.9" length × 3" width × 3" height
• Standards: IEEE Std. C37.41
• Applications: Industrial power distribution, motor protection, transformer circuits
• Class Rating: R
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Diameter: 3 inches
• Weight: 5.9 lb
• Family: CLS
• Type: ACLS

Product Identification

• UPC: 051712527897
• GTIN: 00786670221579
