Bussmann 5ACLS-6R - Medium Voltage Current-Limiting Fuse 170A @ 5080V (Class R, 50kA AIC)

Bussmann 5ACLS-6R is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power systems. It features a 5080V AC voltage rating and a 170A current rating, providing reliable overcurrent protection. The fuse measures 15.9 inches in length with a 3-inch diameter ferrule connection and weighs 5.9 lb, constructed with a single-barrel design for robust performance. Certified to IEEE Std. C37.41 standards, this Class R fuse offers 50kA interrupting capacity at 5.08kV for high-fault current applications. Typical applications include motor circuits, transformers, and feeder protection in industrial facilities requiring medium voltage protection.

Key Features & Specifications

• Type: Medium Voltage Current-Limiting Fuse, Single Barrel, Ferrule Connection
• Voltage Rating: 5080V AC
• Current Rating: 170A
• Dimensions: 15.9" Length × 3" Width × 3" Height
• Standards: IEEE Std. C37.41
• Applications: Industrial motor circuits, transformer protection, feeder circuits
• Class Rating: R
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Diameter: 3 inches
• Weight: 5.9 lb

Product Identification

• UPC: 051712527880
• GTIN: 00786670221517
