Bussmann 5ACLS-5R - Medium Voltage Current-Limiting Fuse 150A 5080V (Class R 50kA AIC)
Regular price
$1,737.45
$1,737.45
Regular price
$1,508.93
$1,508.93
Sale price
$1,737.45
$1,737.45
Save $-228.52
/
- In stock, ready to ship
- Backordered, shipping soon
Bussmann 5ACLS-5R is a medium voltage current-limiting fuse designed for protecting electrical distribution systems and equipment from short-circuit faults. It features a 5080V AC voltage rating with a 150A current rating and provides 50kA interrupting capacity at 5.08kV. The fuse construction utilizes a single-barrel design with ferrule connections, measuring 15.9 inches in length and 3 inches in diameter with a weight of 5.9 lb. This ACLS-type fuse complies with IEEE Std. C37.41 standards and carries Class R rating for rejection of non-current-limiting fuses. Typical applications include industrial power distribution, motor circuits, and transformer protection where high-interrupting capacity is required.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Medium voltage current-limiting fuse, single-barrel construction with ferrule connections
- Voltage Rating: 5080V AC
- Current Rating: 150A
- Dimensions: 15.9" length × 3" diameter
- Standards: IEEE Std. C37.41
- Applications: Industrial power distribution, motor protection, transformer circuits
- AIC rating: [email protected]
- Class Rating: R
- Connection: Ferrule
- Barrels: 1
- Weight: 5.9 lb
- Family: CLS
- Type: ACLS
Product Identification
- UPC: 51712527873
- GTIN: 00786670221456
